Size | 43 cm x 12 cm x 36 cm (17 in. x 5 in. x 15 in.) |
Weight | 8 kg (approximately 17.6 lb) empty |
Power | 120 VAC, 60 Hz, 10 Amps (for P/N 9300408 and 9300409) 240 VAC, 50 Hz, 5 Amps (for P/N 9300410 and 9300411) |
Power Consumption | 1050 Watts |
Electrical Fuses (120V) | 5 x 20 mm, 10A, 250V, FAST BLO (2) |
Electrical Fuses (240V) | 5 x 20 mm, 5A, 250V, FAST BLO (2) |
Aerosol Reagent | PAO-4, DOS (DEHS), Ondina, or mineral oil for Part Number 9300408 and 9300410DOP (DEHP) for Part Number 9300409 and 9300411 |
Liquid Aerosol Reagent Capacity | 1.1 l (64 fl oz) of reservoir capacity |
Compressed Inert Gas Input | 3.45 bar +/- 0.07 bar (50 psi +/- 1.0 psi) |
Compressed Inert Gas Consumption Rate | 6 lpm (0.21 cfm) |
Duct System Requirement | Negative pressure required. Positive duct pressure requires ATI Positive Injection Pump (sold separately). |
Duty Cycle | Intermittent ON/OFF or <4 hours ON and >1 hour off |
Generation | Thermal Vapor |
---|---|
Flow Rate | 833-119,000 m3/hr. (500 – 70,000 cfm) |
Aerosol Output at Max Concentration | 100 µg/m3 @ 11,900m3/hr (100 µg/L @ 7,000 cfm) 10 µg/m3 @ 119,000 m3/hr (10 µg/L @ 70,000 cfm) |
Runtime | 41 minutes (at maximum oil consumption) |
Standards | ISO 14644-3, CE RoHS 2 (2011/65/EU directive) |
